TBR G836

BRAND:: GIANROI

PATTERN:: G836

WARRANTY:: 3-YEAR

MOQ:: 20 PCS

DELIVERY TIME:: 20 DAYS

E-MAIL:: info@gianroitire.cn

DETAILS
SIZES

PATTERN:

◆ GIANROI TIRE G836 PATTERN

FEATURES:

◆ Four wide circumferencial grooves
◆ Siped rib and shoulder design
◆ Reinforced carcass and wide tread
◆ Specially designed compound

BENEFITS:
◆ Ensure excellent water evacuation, even pressure distribution and heat dissipation
◆ Provide excellent heat dissipation
◆ Ensure excellent handling and safe performance
◆ Deliver lower rolling resistance

APPLICABLE VEHICLE MODEL AND ROAD CONDITION:

AVAILABLE SIZES:

SIZE	PR	Tread Depth	RIM	LOAD INDEX	O.D (mm)	S.W. (mm)	INFLATION PRESSURE (kPa)		LOAD CAPACITY (kg)
SIZE	PR	MM	RIM	LOAD INDEX	O.D (mm)	S.W. (mm)	SINGLE	DUAL	SINGLE	DUAL
9R22.5	14	14.00	6.75	136/134L	970	230	830	830	2240	2120
10R22.5	16	15.00	7.50	144/142L	1020	245	860	860	2800	2650
11R22.5	16	15.00	8.25	146/143L	1047	272	830	830	3000	2725
12R22.5	18	16.20	9.00	152/149L	1074	290	930	930	3550	3250
11R24.5	16	14.80	8.25	149/146L	1093	268	830	830	3250	3000
285/75R24.5	14	14.50	8.25	144/141L	1046	272	760	760	2800	2575
285/75R24.5	16	14.50	8.25	147/144L	1046	272	830	830	3075	2800
255/70R22.5	16	15.00	7.50	140/137L	930	255	830	830	2500	2300
275/70R22.5	16	14.50	7.50	140/137L	930	276	830	830	2500	2300
295/75R22.5	16	15.00	9.00	146/143L	1006	288	850	850	3550	3150
295/80R22.5	16	15.00	9.00	152/148M	1039	295	850	850	3550	3150
315/80R22.5	18	15.00	9.00	154/151M	1067	312	830	830	3750	3450

SIZE	PR	Tread Depth	RIM	LOAD INDEX	O.D (mm)	S.W. (mm)	INFLATION PRESSURE (kPa)		LOAD CAPACITY (kg)
SIZE	PR	MM	RIM	LOAD INDEX	O.D (mm)	S.W. (mm)	SINGLE	DUAL	SINGLE	DUAL
9R22.5	14	14.00	6.75	136/134L	970	230	830	830	2240	2120
10R22.5	16	15.00	7.50	144/142L	1020	245	860	860	2800	2650
11R22.5	16	15.00	8.25	146/143L	1047	272	830	830	3000	2725
12R22.5	18	16.20	9.00	152/149L	1074	290	930	930	3550	3250
11R24.5	16	14.80	8.25	149/146L	1093	268	830	830	3250	3000
285/75R24.5	14	14.50	8.25	144/141L	1046	272	760	760	2800	2575
285/75R24.5	16	14.50	8.25	147/144L	1046	272	830	830	3075	2800
255/70R22.5	16	15.00	7.50	140/137L	930	255	830	830	2500	2300
275/70R22.5	16	14.50	7.50	140/137L	930	276	830	830	2500	2300
295/75R22.5	16	15.00	9.00	146/143L	1006	288	850	850	3550	3150
295/80R22.5	16	15.00	9.00	152/148M	1039	295	850	850	3550	3150
315/80R22.5	18	15.00	9.00	154/151M	1067	312	830	830	3750	3450
