TBR G838

BRAND:: GIANROI

PATTERN:: G838

WARRANTY:: 3-YEAR

MOQ:: 20 PCS

DELIVERY TIME:: 20 DAYS

E-MAIL:: info@gianroitire.cn

DETAILS
SIZE

PATTERN:

◆ GIANROI TIRE G838 PATTERN

FEATURES:

◆ Block pattern design
◆ Solid shoulder design
◆ Four wide circumferencial grooves

BENEFITS:
◆ Provide excellent driving and braking force
◆ Provide outstanding resistance to abrasion
◆ Ensure excellent water evacuation, even pressure distribution and heat dissipation

APPLICABLE VEHICLE MODEL AND ROAD CONDITION:

AVAILABLE SIZES:

SIZE	PR	Tread Depth	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	PRESSURE (KPa)		LOAD INDEX(KG)
SIZE	PR	MM	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	SINGLE	DUAL	SINGLE	DUAL
11R22.5	14	23.00	8.25	144/142L	1065	277	720	720	2800	2650
11R22.5	16	22.00	8.25	146/143L	1061	272	830	830	3000	2725
11R24.5	14	21.50	8.25	146/143L	1106	268	720	720	3000	2725
11R24.5	16	21.50	8.25	149/146L	1106	268	830	830	3250	3000
285/75R24.5	14	21.50	8.25	144/141L	1059	272	760	760	2800	2575
285/75R24.5	16	21.50	8.25	147/144L	1059	272	830	830	3075	2800
295/75R22.5	14	23.00	9.00	146/143L	1024	290	830	830	3000	2725
295/75R22.5	16	22.00	9.00	146/143L	1020	288	850	850	3550	3150

SIZE	PR	Tread Depth	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	PRESSURE (KPa)		LOAD INDEX(KG)
SIZE	PR	MM	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	SINGLE	DUAL	SINGLE	DUAL
11R22.5	14	23.00	8.25	144/142L	1065	277	720	720	2800	2650
11R22.5	16	22.00	8.25	146/143L	1061	272	830	830	3000	2725
11R24.5	14	21.50	8.25	146/143L	1106	268	720	720	3000	2725
11R24.5	16	21.50	8.25	149/146L	1106	268	830	830	3250	3000
285/75R24.5	14	21.50	8.25	144/141L	1059	272	760	760	2800	2575
285/75R24.5	16	21.50	8.25	147/144L	1059	272	830	830	3075	2800
295/75R22.5	14	23.00	9.00	146/143L	1024	290	830	830	3000	2725
295/75R22.5	16	22.00	9.00	146/143L	1020	288	850	850	3550	3150
