TBR G835

BRAND:: GIANROI

PATTERN:: G835

WARRANTY:: 3-YEAR

MOQ:: 20 PCS

DELIVERY TIME:: 20 DAYS

DETAILS
SIZES

PATTERN:

◆ GIANROI TIRE G835 PATTERN

FEATURES:

◆ Solid rib design combined with multiple sipes
◆ Four wide circumferencial grooves
◆ Solid shoulder design

BENEFITS:
◆ Provide excellent heat dissipation and improved regular wear with lower resistance
◆ Ensure excellent water evacuation, even pressure distribution and heat dissipation
◆ Provide outstanding resistance to abrasion

APPLICABLE VEHICLE MODEL AND ROAD CONDITION:

AVAILABLE SIZES:

SIZE	PR	Tread Depth	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	PRESSURE (KPa)		LOAD INDEX(KG)
SIZE	PR	MM	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	SINGLE	DUAL	SINGLE	DUAL
11R22.5	14	10.50	8.25	144/142L	1043	275	720	720	2800	2650
11R22.5	16	11.00	8.25	146/143L	1039	272	830	830	3000	2725
12R22.5	18	15.20	9.00	152/149L	1074	290	930	930	3550	3250
11R24.5	16	14.80	8.25	149/146L	1093	268	830	830	3250	3000
285/75R24.5	16	14.50	8.25	147/144L	1046	272	830	830	3075	2800
295/75R22.5	14	10.40	9.00	146/143L	1004	288	830	830	3000	2725
295/75R22.5	16	11.00	9.00	146/143L	998	288	850	850	3550	3150

SIZE	PR	Tread Depth	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	PRESSURE (KPa)		LOAD INDEX(KG)
SIZE	PR	MM	RIM	SPEED INDEX	O.D (mm)	S.W (mm)	SINGLE	DUAL	SINGLE	DUAL
11R22.5	14	10.50	8.25	144/142L	1043	275	720	720	2800	2650
11R22.5	16	11.00	8.25	146/143L	1039	272	830	830	3000	2725
12R22.5	18	15.20	9.00	152/149L	1074	290	930	930	3550	3250
11R24.5	16	14.80	8.25	149/146L	1093	268	830	830	3250	3000
285/75R24.5	16	14.50	8.25	147/144L	1046	272	830	830	3075	2800
295/75R22.5	14	10.40	9.00	146/143L	1004	288	830	830	3000	2725
295/75R22.5	16	11.00	9.00	146/143L	998	288	850	850	3550	3150
